310-MS LC/MS

Retired triple quadrupole LC/MS system; Electrospray/APCI ionization; Wide scan and MRM modes

• Status: Discontinued
• Country: USA
• Analyzer type : Tandem Quadrupole MS
• Scan modes : Full scan, SIM, Precursor scan, Product scan, Neutral loss scan, SRM, MRM
• Mass range : 10 to 2,000 Da
• High resolution : No
• Mass resolution/ Mass resolving power : Unit mass resolution
• Ion source types (LC-MS) : ESI (standard), APCI (optional)
• Dynamic range : 5 orders of magnitude
• Sensitivity : +ESI SIM: 5 pg Reserpine ≥10:1; +ESI MS/MS: 5 pg ≥20:1
• Mass accuracy/Stability : ±0.1 Da over 24 h
• Scanning speed : 500-6000 Da/sec
• Dwell time : <5 ms adjustable
• MRM transition rate : -
• Polarity switching : 240 ms
• Fragmentation : CID via 180° curved collision cell
• Vacuum system : Dual-stage turbomolecular pump (310/400 L/sec) + 1 foreline pump
• Power Requirements and Consumption : MS: 100-240 Vac, 50/60 Hz ±3 Hz, 1.0 kW; Foreline: 100-240 Vac, 50/60 Hz, 2.8 kW
• Environmental requirements : Humidity: 20-80% RH (non-condensing); Temp: 16-30 °C
• Dimensions and Weight: 50.0 × 38.0 × 71.0 cm; 108.0 kg
