8070 Air CO2

CO₂ concentrator and purifier for isotopic analysis. Automates adsorption/desorption with high-purity output. Links to IRMS and ¹⁴C analyzer.

• Status: Active
• Country: Italy
• Measurable isotopes/elements: δ¹³C and ¹⁴C in CO₂
• Device Class (Function) : Gas pre-concentrator
• Technique Compatibility : IRMS
• Brand Independence : Yes
• Available Configurations: Three operation modes: adsorption only, desorption only, or full cycle; portable rechargeable sampler included
• Performance Metrics : Accuracy & precision: <0.1% (certified standard); Sample size 10–100 mg; Analysis time: 10–60 min sampling, 10 min δ¹³C, 1 h ¹⁴C
• Gas supply: Helium 99.999% (3–5 bar); CO₂ 99.999% (3–5 bar)
• Power Requirements and Consumption : 230 V, 50/60 Hz, 1100 W
• Environmental requirements : -
• Dimensions and Weight: Main: 80×50×37 cm, 50 kg; IRMS: 72×46×31 cm, 50 kg; Field sampler: 14×16×40 cm, 3 kg
