320-MS LC/MS

Retired LC/MS with upgradeable single to triple quadrupole; Flexible API/GC interface; Broad scan and SRM modes

• Status: Discontinued
• Country: USA
• Analyzer type : Quadrupole MS (single)
• Scan modes : Full scan, SIM, Precursor scan, Product scan, Neutral loss scan, SRM
• Mass range : Up to 2,000 Da
• High resolution : No
• Mass resolution/ Mass resolving power : Unit mass resolution
• Ion source types (LC-MS) : ESI (standard), APCI (optional), GC interface (optional)
• Dynamic range : 5 orders of magnitude
• Sensitivity : +ESI SIM: 500 fg Reserpine ≥10:1; +ESI MS/MS: 500 fg ≥20:1
• Mass accuracy/Stability : ±0.1 Da over 24 h
• Scanning speed : Up to 6000 Da/sec
• Dwell time : 2-14,000 ms adjustable
• MRM transition rate : -
• Polarity switching : 170 ms
• Fragmentation : CID via 180° curved collision cell
• Vacuum system : Dual-stage turbomolecular pump (310/400 L/sec) + 2 foreline pumps
• Power Requirements and Consumption : MS: 100-240 Vac, 50/60 Hz ±3 Hz, 1.0 kW; Dual foreline pumps: 100-240 Vac, 50/60 Hz, 5.5 kW
• Environmental requirements : Humidity: 20-80% RH (non-condensing); Temp: 16-30 °C
• Dimensions and Weight: 50.0 × 38.0 × 71.0 cm; 108.0 kg
